PET-based Double Sided Tape with Both Shading and Reflection Property No.5680E/No.5682E/No.5684E

Double sided adhesive tape with a special substrate which has excellent light shielding properties.

Contact Us

Customer Support Center

Business Hours (EST) 8:00 a.m.-5:30 p.m.

Except for Sat, Sun, and Holidays


  • Features a black and white special substrate; the white side absorbs almost no light.
  • The adhesive exhibits high adhesion to various adherends.
  • Halogen free. (*Chlorine compounds are purposely not used.)



Product No. Thickness 180° peeling strength
(to stainless steel)
Holding strength [mm]
No.5680E 0.085 mm / 3.34 mil 15.0 N/20mm / 68 oz/in 0.2
No.5682E 0.06 mm / 2.36 mil 13.0 N/20mm / 59 oz/in 0.3
No.5684E 0.05 mm / 1.96 mil 11.0 N/20mm / 50 oz/in 0.5


  • *1 Measured by peeling in a 180° direction at a speed of 300 mm/min with 0.025 mm (0.98 mil) PET lining.
  • *2 Substrate: phenol resin plate; deviation distance was measured after 1 hour of 500 gram loading at 40℃/ 104°F.
  • *The figures are a sample of observed values, not guaranteed performance.


  • Fixing of LCDs and backlight modules.
  • Fixing and blocking light of backlight LCDs.
