Low-VOC, Solvent-free, Thick Double Sided Tape No.515

Thick-type solvent-free double sided adhesive tape low VOC emission. No.515 is a thick-type double sided adhesive tape, focusing on “firm bonding” and “user friendliness”, the tape can be used for a wide range of materials such as backup materials for interior fixtures as well as plastics and metals.

Download

Features

  • A double sided adhesive tape with a VOC(*) emission level lower than the indoor air quality value designated by the Ministry of Health, Labor and Welfare. (*) : volatile organic compound
  • Tape with 0.25mm/ 9.84 mil thickness adheres well to uneven surfaces.
  • Uses nonwoven fabric carrier so it adheres well to the surface to which it is applied and follows the contour of the substrates.

Structure

Properties

180° peeling strength according to type of substrate



SubstrateAdhesive Strength
Stainless steel16.5 N/20mm
Acrylic16.5 N/20mm
Polystyrene14.5 N/20mm
Lauan14.0 N/20mm
SubstrateAdhesive Strength
Stainless steel75.4 oz/in
Acrylic75.4 oz/in
Polystyrene66.2 oz/in
Lauan64 oz/in

[Remarks]

  • * Measured by peeling in a 180° direction at a speed of 300 mm/min at 23°C/73°F with 0.025 mm/ 0.984 mil PET lining.

180° peeling strength according to temperature (stainless steel)



Test TemperatureAdhesive Strength
10℃/ 50°F17.0 N/20mm/ 77 oz/in
23℃/ 73°F16.5 N/20mm/ 75.4 oz/in
40℃/ 104°F15.0 N/20mm/ 68.5 oz/in
60℃/ 140°F14.3 N/20mm/ 65.3 oz/in

[Remarks]

  • * Measured by peeling in a 180° direction at a speed of 300 mm/min 23°C/73°F with 0.025 mm/ 0.984 mil PET lining. Tape pressure application and measurement at temperatures given in the table above.

Lineup

Lineup double sided adhesive tapes with VOC(*) emission level lower than the guideline values for indoor air concentrations set by the Ministry of Health, Labor and Welfare.

Product No.Tape ThicknessColorPoints for selection
No.5100.15 mm/ 5.9 milWhite translucentStandard item for bonding metals and plastics.
No.5120.15 mm/ 5.9 milWhite translucentSuitable for rough surfaces with its strong tackiness.
No.5150.25 mm/ 9.84 milWhite translucentA product to be used when a certain amount of tape thickness is necessary.

[Remarks]

  • * The above values are sample observed values, not the guaranteed performance.
  • * The applications given herein are suggested examples. Please make sure the product is capable of the application before actually attempting to put it to use.

Applications

  • For fixing backup materials of interior fixtures.
  • For fixing metal display panels.
  • For fixing plastic display panels.
